ปั๊มไดอะแฟรม CHEMPRO รุ่น DP80 ตัวปั๊มผลิตจากวัสดุพลาสติก ประเภท AL มีจุดเด่นในเรื่องของทนทานการกัดกร่อนจากสารเคมีได้ดี
ไดอะแฟรมปั๊ม มีการทำงานแบบดูด-อัด ออกแบบมาอย่างดีเยี่ยม มีความต้านทานต่อการกัดกร่อน ทนต่อแรงดัน ได้ดีและมีอายุการใช้งานยาวนาน ติดตั้งในพื้นที่ที่มีประกายไฟได้ (Explosion Proof) เนื่องจากใช้ลมในการขับเคลื่อน มีอุปกรณ์ภายในน้อย สะดวกในการดูแลรักษา หรือซ่อมบำรุง ราคาไม่แพง สามารถติดตั้งได้หลายรูปแบบ มีความยืดหยุ่นในการติดตั้ง ทำให้มีการใช้งานอย่างแพร่หลายในอุตสาหกรรมต่างๆ
ลักษณะทั่วไป
Material Quality | |
Pump body | Aluminum |
Diaphragm | Santoprene, Hytrel, teflon, Viton, EPDM, Buna-N |
Valve Seat | Teflon, Santoprene, Hytrel, Viton, Stainlees stee |
Valve Ball | Teflon, santoprene, Hytrel, Viton, Ceramic |
Center block | PP, Aluminum, Stainlees stee |
Technical Parameter | ||
Suction lift [mwc] | dry | 5 |
wet | 8 | |
Max particle diameter [mm] | 9.4 | |
Suction and discharge Size [in] | 3″ | |
AIR inlet size [in] | 3/4 | |
Max frow [I/min] | 1060 | |
Maxhead [m] | 84 | |
Max air inlet pressure [bar] | 8.4 |
