| Description |
|
Standard |
|
|
Optional |
| 2 poles model |
4 poles model |
2 poles model |
4 poles model |
| Liquid |
Name |
Clean water |
|
| Temperature |
Oto 80*0(32 to 176*F) |
|
| Max Working Pressure |
10 bar (10.2 kgf/cm2) for standard flange JIS 10K RF |
16 bar (16.3 kgf/cm2) |
| 16 bar (16.3 kgf/cm2) for standard flange JIS 16K RF |
|
| Synchrounous Speed |
3000 min’1 |
1500 mln’ |
|
| Instalation |
Indoors |
Outdoors |
| Construction |
Impeller |
Enclosed |
|
| Shaft seal |
Mechanical seal |
Gland Packing |
| Sealling |
Self flushing |
External flushing |
| Bearing |
Sealed ball bearing |
Oil bath (some models only) |
| Flange |
Suction & Discharge |
Suction < $ 150 mm, except 100×65 FSKA |
: JIS 10K RF |
16 bar: JIS 16K RF; DIN PN-16 |
| 100×65 FSKA |
:JIS16K RF |
DIN PN-16 |
| Suction = d 150 mm, except below models |
:JIS10KRF |
16 bar: JIS 16K RF; DIN PN-16 |
| 150×100 FSKA; 150×100 FSNA |
: JIS 16K RF |
DIN PN-16 |
| Suction = o 200 mm, except below models |
: JIS 10K RF |
16 bar :JIS 16K RF; DIN PN-16 |
| 200×150 FSLA; 200×150 FSNA |
: JIS 16K RF |
DIN PN-16 |
| Suction = o 250 |
: JIS 16KRF |
DIN PN-16 |
| Matenal |
Casing |
Cast Iron |
Ductile Cast Iron (FCD) |
| Impeller |
Bronze Casting (CAC406/BC6) |
Cast iron; Ductile Cast Iron (FCD) |
| Shaft |
403 Stainless steel |
304; 316 Stainless steel |
| Seal |
Mechanical Seal: Ceramic/Carbon/NBR |
Gland Packing : Teflon (PTFE) impregnated Mechanical Seal: SiC/SiC |
| Accessories |
Bare shaft |
|
Priming funnel; valve; Companion Flange |
| With motor |
Common base, Coupling, Coupling guard |
Priming funnel; valve: Companion Flange |
